ITEM NO: PSI800-12

With PSI800-12 Inverter you can run your phone, laptops and TV’s. Using a Pure Sine Wave output, the inverter will ensure appliances run smoothly and efficiently, producing less heat and noise. Ultra-compact metal housing is lightweight, rugged and easily stores in any tool box or glove box.

• Integrated Fuse Protection: Protects your battery and inverter from damage due to outlet overload

• The inverter can automatically detect low battery voltage and shut down to preserve the battery

• Overload protection: shutdown and alarm (integrated fuse protection, protects the battery, and inverter from damage due to outlet overload)

• Output short: Output short circuit protection

• Battery protection reverse: By fuse



  FEATURES:

• DC input voltage: 12V DC, 100A, (10-15V)

• Input standby current (12V DC,+/-5%): ≤0.5A

• AC output voltage: 230V AC / 115V AC, +/-8%

• Output power: 800W

• Output power (peak watts): 1600W

• USB Output Voltage: 5.0V DC, 2.4A

• Output frequency: 50 or 60Hz

• Output waveform: Pure Sine Wave

• Low-battery voltage alarm: 10.5V DC,+/-0.5V

• Low-battery voltage shutdown: 10.0V DC, +/-0.5V

• Fuse quantity & size: 40A×2 , Standard auto blade fuse (External)

• Efficiency: 85 to 90%

• Thermal shutdown: 65℃+/-5℃

• Cooling fan: Yes

• Operating temperature: 0~40℃

• Storage temperature: -15℃~45℃

• Operating relative humidity: 10%RH~102%RH

• Machine size(mm): 254×144×68

• N.W.(Kgs): 1.18Kg
